Our 4ft Straight Picket Top Semi Privacy Fence is similar to our White Vinyl Privacy Fence Panel with Straight Picket Top. This fence cleverly balances privacy and openness, providing a tranquil and comfortable relaxation area. Allowing soft light and breezes to permeate, maintaining a sense of spaciousness. The clean, flowing straight picket top design boasts elegant lines and a classic, sophisticated look. It adapts to various architectural styles, adding a touch of elegance to your yard.
Crafted from select high-quality vinyl (PVC) material. This material offers superior weather resistance, easily withstanding UV rays, rain, wind, and temperature fluctuations, ensuring the fence is resistant to cracking, peeling, or rust, maintaining its beauty and functionality for a long time.
Our vinyl fence requires virtually no maintenance; a simple wipe with water is all it takes to restore its pristine shine. This allows you more time to enjoy life, rather than the hassle of maintenance. The pure, simple white brightens your yard, creating a bright, clean, and open visual effect. Our user-friendly design makes installation simple and quick. Even DIY enthusiasts can easily and efficiently complete the installation and quickly have their ideal fence.
As an experienced fence supplier, we understand that every project is unique. In addition to standard sizes and colors, we also offer professional customization services. You can personalize the size, color, and other aspects to create your ideal fence tailored to your specific needs.
 |
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Picket with Caps | 76.2×22.3×1150 | 2.0 | 15 |
| Alum | 2388 | 1 | |
| Post | 102×102×1900 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Picket with Caps | 76.2×22.3×1150 | 2.0 | 22 |
| Alum | 2388 | 1 | |
| Post | 102×102×1900 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
|
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Picket with Caps | 38.1×38.1×1150 | 2.0 | 24 |
| Alum | 2388 | 1 | |
| Post | 102×102×1900 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
 |
| Arbor Caps | External Flat Cap | Flat Cap |
 |
 |
 |
| Gothic Cap | Sharp Point Cap | New England Cap |
PVC resin and various additives are uniformly mixed in a high-efficiency mixer according to precise formula ratios. This process is crucial and directly affects the quality of the final product.
The mixed PVC granules or powder are fed into an extruder. Under heating and rotation, the molten PVC material is extruded through a die and immediately cooled. The cooled PVC profile is then pulled out at a constant speed by a traction machine, thus controlling the size and thickness of the profile.
Once the continuously extruded PVC profile reaches the set length, an automatic cutting machine automatically cuts the profile into the required fence components, such as posts, crossbars, and slats. The cut components undergo quality inspection to check for smooth cut surfaces, burrs, cracks, and other defects.
According to the drawings, milling equipment is used to pre-drill holes in the components to be connected, and necessary milling operations, such as milling grooves and edges, are performed. The position, diameter, and depth of the drilled holes must be strictly controlled according to the drawing requirements.
Clean all parts of the cut and milled PVC fence to remove dust, oil, debris, and other impurities. Cleaning can be done by water washing, solvent cleaning, or ultrasonic cleaning to ensure a clean surface.
Prepare all materials needed for assembling the PVC fence, including cut and milled PVC parts, connectors, and any other hardware. Assemble the components using specialized assembly tools according to design requirements and assembly drawings. During assembly, ensure that all connections are secure, tight, and dimensionally accurate.
Conduct a thorough quality inspection on each product to ensure customers receive only the highest quality products. This step includes checking each assembled fence for defects and ensuring all components are securely connected and meet established standards.
Pack the qualified PVC fence components according to customer requirements, typically using packing straps, plastic film, or wooden pallets for securing and protection to prevent damage during transportation.
 |
 |
 |
