This product is a 6ft Semi Privacy Vinyl Fence system that provides high privacy while maintaining visual openness. Compared to our 5ft Semi Privacy Vinyl Fence., the 6 ft height offers a superior sense of space and enclosure.
The lower half of the fence features fine, uniform slits that effectively block ground-level views, creating a private space. The upper half consists of five symmetrically distributed high-strength vinyl posts, ensuring structural stability while forming a continuous visual barrier, effectively preventing peeping and avoiding the oppressive feeling of complete enclosure. Viewed from the side, the fence forms a continuous visual barrier, ensuring the privacy of the yard. The wide fence panels enhance the overall structural strength and security.
We use high-quality, environmentally friendly polyvinyl chloride (PVC) material, which boasts excellent weather resistance, UV resistance, and chemical corrosion resistance. The material is stable, resistant to aging, cracking, and fading, significantly extending the fence’s lifespan. The smooth surface is easy to clean, requiring no regular painting or anti-corrosion treatments, greatly reducing maintenance costs for homeowners.
As a professional fence manufacturer, we offer a variety of colors and styles to suit different architectural styles and landscape designs. The spacing between fence panels can be flexibly adjusted according to project needs to meet varying degrees of transparency requirements.
|
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Middle Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×152.4×2388 | 2.8 | 1 |
| Top Picket | 38.1×22.3×375 | 2.0 | 5 |
| Picket | 38.1×22.3×1235 | 2.0 | 24 |
| Alum | 2388 | 1 | |
| Post | 127×127×2500 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Middle Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×152.4×2388 | 2.8 | 1 |
| Top Picket | 76.2×22.3×375 | 2.0 | 5 |
| Picket | 76.2×22.3×1235 | 2.0 | 15 |
| Alum | 2388 | 1 | |
| Post | 127×127×2500 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
||
| Item | Dimension | Thickness | Qty |
| Top Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Middle Rail | 50.8×88.9×2388 | 2.8 | 1 |
| Bottom Rail | 50.8×152.4×2388 | 2.8 | 1 |
| Top Picket | 38.1×38.1×375 | 2.0 | 5 |
| Picket | 38.1×38.1×1235 | 2.0 | 24 |
| Alum | 2388 | 1 | |
| Post | 127×127×2500 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
 |
| Arbor Caps | External Flat Cap | Flat Cap |
 |
 |
 |
| Gothic Cap | Sharp Point Cap | New England Cap |
PVC resin and various additives are uniformly mixed in a high-efficiency mixer according to precise formula ratios. This process is crucial and directly affects the quality of the final product.
The mixed PVC granules or powder are fed into an extruder. Under heating and rotation, the molten PVC material is extruded through a die and immediately cooled. The cooled PVC profile is then pulled out at a constant speed by a traction machine, thus controlling the size and thickness of the profile.
Once the continuously extruded PVC profile reaches the set length, an automatic cutting machine automatically cuts the profile into the required fence components, such as posts, crossbars, and slats. The cut components undergo quality inspection to check for smooth cut surfaces, burrs, cracks, and other defects.
According to the drawings, milling equipment is used to pre-drill holes in the components to be connected, and necessary milling operations, such as milling grooves and edges, are performed. The position, diameter, and depth of the drilled holes must be strictly controlled according to the drawing requirements.
Clean all parts of the cut and milled PVC fence to remove dust, oil, debris, and other impurities. Cleaning can be done by water washing, solvent cleaning, or ultrasonic cleaning to ensure a clean surface.
Prepare all materials needed for assembling the PVC fence, including cut and milled PVC parts, connectors, and any other hardware. Assemble the components using specialized assembly tools according to design requirements and assembly drawings. During assembly, ensure that all connections are secure, tight, and dimensionally accurate.
Conduct a thorough quality inspection on each product to ensure customers receive only the highest quality products. This step includes checking each assembled fence for defects and ensuring all components are securely connected and meet established standards.
Pack the qualified PVC fence components according to customer requirements, typically using packing straps, plastic film, or wooden pallets for securing and protection to prevent damage during transportation.
